X10 / X10+ Real Time LiDAR Monitoring And Data Collection
| MOQ: | 1 set |
| Price: | Contact us |
| Standard Packaging: | Tool Case |
| Delivery Period: | 2 weeks |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 100 sets per Month |
X10+ lidar scanner device
,X10 lidar scanner device
,120m lidar system
The EasyScan X10/X10+ integrates cutting-edge LiDAR, GNSS, and high-precision IMU with an aerial metric camera for unparalleled accuracy in aerial and ground surveying. With its modular design, this system can switch between airborne and SLAM modes, ensuring optimal data capture in any scenario.
| Attribute | Value |
|---|---|
| Brand | EPiC LiDAR |
| Model | X10 / X10+ |
| Working Mode | Handheld SLAM and Aerial |
| Dataset | Contact us |
| Accuracy | 5cm |
| Flying Height | Suggested 80m-120m |
| System Parameters | |
|---|---|
| Weight | 280g |
| Dimension | L159×W118×H127(mm) |
| Average Power Consumption | 25W (X10) / 26W (X10+) |
| Power Supply | 10~30V DC |
| Device Interface | DJI Skyport/other interface available upon request |
| Data Storage | USB-disk 256GB |
| Operating Temperature | -10℃~50℃ |
| Storage Temperature | -30℃~60℃ |
| System Accuracy | 5cm |
| Compatible Platform | DJI M300 RTK/Other UAV models |
- High Efficiency: Ultra-light aerial survey module with increased flight height capability for improved operation efficiency
- Light Independent: LiDAR performance unaffected by environmental lighting conditions, with effective night operation
- Signal Flexibility: SLAM mobile scanning mode eliminates GNSS signal limitations for complete indoor/outdoor data integration
- Real-time Monitoring: Simultaneous point cloud and orthophoto acquisition with full-flight trajectory monitoring
X10 Package: 16 lines scanner ×1, Camera ×1, Skyport ×1, Software dongle ×1, Camera Adapter ×1, GNSS receiver ×1
X10+ Package: 32 lines scanner ×1, Camera ×1, Skyport ×1, Software dongle ×1, Camera Adapter ×1, GNSS receiver ×1, SLAM handheld holder ×1
EasyScan X10+ applied to measure an underground parking lot:
Note: The technical parameters and configuration of our products are subject to change without notice.
① Weight includes LiDAR, GNSS, high-precision IMU, and aerial metric camera module
② Perpendicular to the flight direction, with the effective FoV angle of LiDAR
③ Weight includes main body, SLAM dock, telescopic rod, and camera
④ Tested at 25°C~27°C; charging time and power supply time will vary according to different conditions
