Versatile LiDAR EasyScan X10 / X10 For Airborne And Handheld Use
| MOQ: | 1 set |
| Price: | Contact us |
| Standard Packaging: | Tool Case |
| Delivery Period: | 2 weeks |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 100 sets per Month |
Detail Information
Place of Origin
China
Brand Name
EPiC LiDAR
Certification
CE, FCC
Model Number
EasyScan X10 / X10+
Brand:
EPiC LiDAR
Model:
X10 / X10+
Working Mode:
Handheld SLAM And Aerial
Dataset:
Contact Us
Accuracy:
5cm
Flying Height:
Suggest 80m-120m
Highlight:
EasyScan 3d scanning machine
,Airborne 3d scanning machine
,Handheld uav lidar system
Product Description
Versatile LiDAR EasyScan X10 / X10+ For Airborne And Handheld Use
Product Overview
The EasyScan X10/X10+ integrates cutting-edge LiDAR, GNSS, and high-precision IMU with an aerial metric camera for unparalleled accuracy in aerial and ground surveying. With its modular design, this system can switch between airborne and SLAM modes, ensuring optimal data capture in any scenario.
Key Specifications
| Attribute | Value |
|---|---|
| Brand | EPiC LiDAR |
| Model | X10 / X10+ |
| Working Mode | Handheld SLAM and Aerial |
| Accuracy | 5cm |
| Flying Height | Suggested 80m-120m |
Technical Specifications
System Parameters
| Parameter | X10 | X10+ |
|---|---|---|
| Weight | 280g | 280g |
| Dimensions | L159×W118×H127(mm) | |
| Power Consumption | 25W | 26W |
| Power Supply | 10~30V DC | |
| Data Storage | USB-disk 256GB | |
| Operating Temperature | -10℃~50℃ | |
| System Accuracy | 5cm | |
Laser Unit
| Parameter | X10 | X10+ |
|---|---|---|
| Scanning Point Frequency | Single: 320,000pts/s Dual: 640,000pts/s |
Single: 640,000pts/s Dual: 1,280,000pts/s |
| Measurement Range | 0.05m~120m@10% Reflectivity | |
| Horizontal FoV | 360° | |
Key Features
High Efficiency: Ultra-light aerial survey module allows increased flight height for improved operation efficiency.
Not Affected by Light: LiDAR performs consistently regardless of lighting conditions, with effective night operation.
No Signal Limitation: SLAM mobile scanning mode works without GNSS signal limitations for complete indoor/outdoor data.
Real-time Monitoring: Simultaneous acquisition of point cloud and orthophoto with real-time flight monitoring.
Included Accessories
X10: 16 lines scanner, Camera, Skyport, Software dongle, Camera Adapter, GNSS receiver
X10+: 32 lines scanner, Camera, Skyport, Software dongle, Camera Adapter, GNSS receiver, SLAM handheld holder
Applications
Smart Grid
Topographic Mapping
Emergency Rescue
Smart Mining
Civil Engineering
Pipeline Inspection
Case Study
EasyScan X10+ applied to measure underground parking lot:
Sample Data
*The technical parameters and configuration of our products are subject to change without notice.
