EasyScan X10 / X10+ High Efficiency LiDAR For Complex Environments
| MOQ: | 1 set |
| Price: | Contact us |
| Standard Packaging: | Tool Case |
| Delivery Period: | 2 weeks |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 100 sets per Month |
EasyScan 3d lidar system
,X10+ 3d lidar system
,X10 3d laser scanner
| Attribute | Value |
|---|---|
| Brand | EPiC LiDAR |
| Model | X10 / X10+ |
| Working Mode | Handheld SLAM and Aerial |
| Dataset | Contact us |
| Accuracy | 5cm |
| Flying Height | Suggest 80m-120m |
Easy Scan X10 / X10+ Versatile 3D laser Scanner Handheld SLAM and Airborne Drone LiDAR
Multiple views from one
The EasyScan X10/X10+ integrates cutting-edge LiDAR, GNSS, and high-precision IMU with an aerial metric camera for unparalleled accuracy in aerial and ground surveying. With its modular design, this system can switch between airborne, SLAM modes, ensuring optimal data capture in any scenario. Whether for UAV-based surveys or mobile scanning, it's your one-stop solution for topographic mapping, smart grids, and civil engineering projects.
This system operates efficiently in all lighting conditions, gathering high-density data even at night. It's a versatile tool that switches seamlessly between GNSS-based UAV scanning and GNSS-free SLAM scanning, enabling consistent data collection indoors and outdoors.
| System Parameter | |
|---|---|
| Weight | 280g |
| Dimension | L159*W118*H127(mm) |
| Average Power Consumption | 25W | 26W |
| Power Supply | 10~30V DC |
| Device Interface | DJI Skyport/other interface available upon request |
| Data Storage | USB-disk 256GB |
| Operating Temperature | -10℃~50℃ |
| Storage Temperature | -30℃~60℃ |
| System Accuracy | 5cm |
| Compatible Platform | DJI M300 RTK/Other UAV models |
| Laser Unit | |
|---|---|
| Scanning Principle | Mechanic Rotation Mirror |
| Laser Class | ClassⅠ |
| Wavelength | 905nm |
| Measurement Range | 0.05m~120m@10%Reflectivity |
| Range Accuracy | ± 1cm |
| Horizontal FoV | 360° |
| Vertical FoV | 30°(-15~+15°) | 31°(-16~+15°) |
| Scanning Point Frequency | Single Return:320,000pts/s Dual Return:640,000pts/s | Single Return:640,000pts/s Dual Return:1,280,000pts/s |
| Return Mode | Single Return/Dual Return |
| GNSS & IMU | |
|---|---|
| GNSS Signal Tracking | BDS,GPS,GLONASS,GALILEO |
| Positioning Accuracy(post-processing) | Plane:1cm/Elevation:2cm |
| Position Data Rate | ≥5HZ |
| Attitude Accuracy(post-processing) | Heading:0.05°/pitch/roll:0.01° |
| Attitude Data Rate | ≥200HZ |
| Aerial Camera (External) | |
|---|---|
| Effective Pixels | 26MP |
| Sensor Dimension | 23.5×15.7mm |
| Image Resolution | 6252×4168 |
| Image Width FoV | 73° |
| GSD | 2.3cm@100m Flight Height |
| SLAM Unit (Optional) | |
|---|---|
| Weight | 1051g(Battery not Included) |
| Dimension | L136W149 H108(mm) |
| Scanning Mode | Fix Installed |
| Battery Duration | 4h for Single Battery |
| Accuracy | Relative Accuracy 2cm/Absolute Accuracy 5cm |
*The technical parameters and configuration of our products are subject to change without notice.
Notice:
① Weight includes LiDAR, GNSS,high-precision IMU, and aerial metric camera module
② Perpendicular to the flight direction, with the effective FoV angle of LiDAR
③ Weight includes main body,SLAM dock, telescopic rod, and camera
④ Tested at 25°C~ 27°C; charging time and power supply time will vary according to different conditions
- High efficiencyUltra-light aerial survey module, image acquisition not limited by LiDAR measurement range, flight height can be appropriately increased to improve the operation efficiency.
- Not affected by lightLiDAR is not affected by the environment, has less side overlap, wider coverage of a single flight, and data can be easily collected even at night.
- No signal limitationSwitch to SLAM mobile scanning mode, no limitation of GNSS signal, indoor and outdoor data integrated, collection makes the 3D data more complete.
- Real-time monitoringSimultaneous acquisition of point cloud and orthophoto to achieve the real-time monitoring of flight trajectory, 3D point cloud, and images during the whole flight of the system.
X10:
16 lines scanner *1
Camera *1
Skyport *1
Software dongle *1
Camera Adapter *1
GNSS receiver *1
X10+:
32 lines scanner *1
Camera *1
Skyport *1
Software dongle *1
Camera Adapter *1
GNSS receiver *1
SLAM handheld holder *1
EasyScan X10+ is applied to measure the underground Parking Lot
