Terrestrial 3D Laser Scanner EasyScan T05 For BIM Construction Measurement Digital Twins
  • name
  • name
  • name

Terrestrial 3D Laser Scanner EasyScan T05 For BIM Construction Measurement Digital Twins

MOQ: 1 set
Price: Contact us
Standard Packaging: Tool Case
Delivery Period: 2 weeks
Payment Method: L/C, T/T
Supply Capacity: 100 Sets/ Month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
EPiC LiDAR
Certification
CE, FCC, ISO9001...
Model Number
EasyScan T05
Measurement Range:
0.5~100m@20%
FoV:
Horizontal 360°， Vertical 268°
Accuracy:
1cm@100m
Weight:
3.7kg
Point Cloud Density:
10m: >25,000 Pts/㎡
HDR Imaging:
Yes
Highlight:

20W Terrestrial 3D Laser Scanner

,

100m Terrestrial 3D Laser Scanner

,

0.5m terrestrial lidar scanner

Product Description

Terrestrial 3D Laser Scanner EPiC LiDAR EasyScan T05 for BIM construction measurement digital twins

Product Introduction



Lightweight & Exquisite | Easy scanning



The overall design of the system is extremely lightweight, and a variety of sensors are highly integrated, which can ensure the rapid and effective acquisition of high-precision true color point clouds under different application scenarios, and lead a new development direction of the terrestrial 3D laser scanner.



Product Specification

















System Parameter

 Weight 3.7kg
Dimension LI25*WI24*H265mm
Average Power Consumption 20W
Battery Duration 2hr For single Bbattery
FoV Horizontal 360°,Vertical 268°
Data Storage U-Disk 64GB
Operating Temperature -10C~50C
Storage Temperature -20C~60℃



Aluminum Alloy tripod

Weight:1.92kg

Safe Load:8kg

max.Height:1.49m









Laser Scanning Unit

 Scan Principle ToF
Laser Class Class I
Wavelength 905nm
Measurement Range 0.5m～100m@20%
Scanning Point Frequency 320,000pts/s







Operation Performance

 Precision 1cm@100m
Ranging Accuracy 5mm@10m,8mm@30m,Icm@100m
Minimum Data Collection Time 60s



Point Density

 0m:>25,000pts/m²
30m:>3,200pts/m²
00m:>300pts/m²
Embedded Camera FoV 360°
mage Resolutio 66MP





Features:



High Integration



With three embedded high-definition cameras and one smart battery.



High Accuracy



5mm point cloud accuracy and pixel-level colorization.



Intelligent Workflow



Once-click to collect data, it can calculate and splice data automatically.





Application:



Terrestrial 3D Laser Scanner EasyScan T05 For BIM Construction Measurement Digital Twins 0

     Infrastructure                   Digital               Underground                    BIM                          Mine                        Tank

     Management                    Plant                                                                                     Monitoring                Calibration







Accessories







Case



EasyScan T05 Applied to Forestry Surveying in Japan



Terrestrial 3D Laser Scanner EasyScan T05 For BIM Construction Measurement Digital Twins 1





Sample Data Display



Terrestrial 3D Laser Scanner EasyScan T05 For BIM Construction Measurement Digital Twins 2Terrestrial 3D Laser Scanner EasyScan T05 For BIM Construction Measurement Digital Twins 3Terrestrial 3D Laser Scanner EasyScan T05 For BIM Construction Measurement Digital Twins 4
